General Specs |
| Product Weight (lbs.) | 105 |
| Color | Stainless Steel |
| Depth Excluding Handles (in.) | 24 |
| Depth Including Handles (in.) | 24.88 |
| Steam | No |
| Depth w/Door Open 90 Degrees (in.) | 51 |
| ENERGY STAR Certified | Yes |
| Number of Cycles | 5 |
| Delay Wash (Up to hours) | 12 |
| Depth (in.) | 24 |
| Handle Color | Stainless Steel |
| Handle Type | Arch |
| Height (in.) | 34 |
| Interior (Settings) | 16 |
| Noise level (dB) | 45 |
| Tub Material | Stainless Steel |
| Width (in.) | 23.75 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 24 |
| Wifi Connectivity | Yes |
| Sanitize Option | Yes |
| Smart Compatible | No |
| Color Finish Name | Stainless Steel |
| Number Of Place Settings | 16 |
| ADA Compliant | No |
| Cut Out Width | 24 |
| Cut Out Height | 34.75 |
| Dishwasher Type | Built-In |
| Control Panel Type | Top |
| Cut Out Depth | 24 |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 6.6 |
| Sound Rating Range | Quieter |
| Dishwasher Features | 3rd Rack, Wi-Fi Capable, Food Disposal, Food Filter, Movable Tines, Leak Sensor, Cutlery Holder, Bottle Washing Sprayers, Fingerprint Resistant Finish, Sensor Wash, Wi-Fi Capable |
| Third Rack | Yes |
Features |
| Tub Type | Tall Tub |
| Control Type | 8 Touchpads
Cap Touch Controls
Top Controls |
| Dishwasher Control Features | 1 "Clean" Light, 1 "Sanitized" Light Cycle Progress Indicators
3 Digit Display Cycle Countdown with Bi-Color LED Status Light on door
Audible End-of-Cycle Signal
Last Cycle Memory
White LEDs |
| Wash System | 3-Level
700 Series |
| Wash System Features | 140+ Spray Jet Wash System
Automatic HotStart
Automatic Temperature Control
Bottle Jets (4)
Deep Clean Silverware Jets
Drain Pump
Dual Pumps and Motors
Piranha™ Hard Food Disposer with removable filter
Quad Blade Middle Wash Arm
Reversing Quad Blade Lower Wash Arm |
| Sensor | Clean Sensor |
| Wash Arms | 3 Wash Levels
Bottle Jets
Jets - Variable Pressure
Lower- Reversing Quad Blade
Middle - Quad Blade
Side Jets |
| Water Filtration System | 100% Filtration with Piranha Hard Food Disposer and Removable Filter |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | 1 Hour Wash
Auto Sense
Heavy Wash
Light Wash
Normal Wash |
| Number of Options | 10 |
| Dishwasher Options | Bottle Jets
Child Lock
Delay Start 1-12 Hr.
Dry Boost™
Heated Dry
Sani (NSF 184 Certified)
Start/Reset
Steam PreWash
Wash TempBoost
Wash Zone Lower Only
Wash Zone Upper Only |
| Rack Features | 1 Piece Silverware Basket with 3 Cell Covers
Adjustable Upper Rack
Ball-Tipped Tines
Fold-Down Tines - Lower
Fold-down tines - Upper |
| Racking Material | Nylon |
| Racking System | Full 3rd rack |
| Rack Color | Silver |
| Upper Rack | 1 Rack handle
1/2 fixed tines, 1/2 fold down tines
Ball-Tip Tines
Premium Height Adjustable |
| Lower Rack | 1 Rack handle
Ball-Tip Tines
Multi-Position Fold Down Tines |
| Additional Protection | Active Flood Protect |
| Cutlery Tray | One piece removable 3rd rack |
| Dishwasher Drying Features | Dry Boost™
Fan Assist Dry
Heated Dry - On/Off
Multi-Wattage Wash & Dry Element |
| Floor Protection | Water leak sensor; active flood protect |
| Leveling System | 4 Leveling Legs |
| Latch | Pull with Handle |
| Showroom Power Mode | Yes |
| WiFi Connect | Built-In |
| Exterior Style | Traditional |
Appearance |
| Door Style | Long Door with Top Controls |
| Installation | Built-Up Floor Capable
Flush Cabinet Installation
Side Installation or Top Installation Included |
| Door Appearance | Full-length door |
Economical/Quiet |
| Motor Type | Single Speed |
| Outer Wrap | Bitumen
Full-wrap Blanket |
| Door Insulation | Insulation
Mastic |
Weights and Dimensions |
| Cabinet Width | 24 in |
| Height w/ Legs Retracted - Minimum Height | 33 3/8 in |
| Height w/Legs Extended - Maximum Height | 34 5/8 in |
Power/Ratings |
| Calrod Heater Watts | 800/500 |
| Power Connection | Optional cord kit (GPFCORD - WX09X70910, WX09X70911) |
